Special Closure Lids Visual Inspection Machine With HD Industrial Cameras
Inspection standard
| Model | Number of camera | Inspection scope | Inspection content | Precision | Speed |
| KVIS-C-SC006 | 1 set | Top area | 0.2mm＜Black spot | 99% | 800-1200pcs/min |
| 0.5mm＜Rag | 99% | ||||
| 0.5mm＜Oily dirty (with obviously color difference) | 99% | ||||
| 4 sets | Visible position of the side of the outer cover and the inner cover | 0.2mm＜Black spot | 99% | ||
| 0.5mm＜Oily dirty (with obviously color difference) | 99% | ||||
| 1 set | Cover bottom and inside of cover bottom | 0.2mm＜Black spot | 99% | ||
| 0.5mm＜Injection incomplete, flash | 99% | ||||
| 0.5mm＜Oily dirty (with obviously color difference) | 99% |
Inspection principle
Water, beverage, pharmaceutical and other production enterprises have extremely strict quality requirements for product appearance. Industry production is becoming more and more refined, and standards are getting higher and higher. Inspection work must implement high standards. Traditional manual inspection methods, regardless of speed or efficiency, are difficult to follow.
Due to the needs of mass production, the detection results are easily affected by the emotions and energy of workers, and the false detection and missed detection rate is high. The fully automatic inspection machine based on machine vision technology eliminates this drawback and provides a good opportunity for greatly improving production efficiency and optimizing product processes.
Inspection details
Our design plan adopts 11 sets of high-pixel industrial cameras and high-performance stroboscopic light sources to carry out all-round visual inspection for the appearance defects of bottle cap products. The inspection speed can reach 400 pieces/min, and the equipment can achieve 7*24 hours. It operates around the clock, and the unqualified products can be automatically rejected online.
The whole set of testing equipment includes material handling
equipment, mechanical structure, visual electronic hardware and
testing system software, which can be independently arranged on the
customer site, and can be equipped with production line equipment
such as dust removal and disinfection according to the specific
production needs of the customer site.
Features of system
Company profile
KEYETECH has always been committed to the application of artificial intelligence in the field of vision technology, replacing human eyes and brain decision with machine vision and AI reasoning calculations, and integrating the quality detection and sorting to industrial products in traditional manufacturing to make the production more digitization , Intelligence, visualization, and persistence. Also greatly improves the efficiency and accuracy of industrial detection, and enhances the intelligent level of the manufacturing industry.
|
|
